Manual Bandsaw Machine
Precision-focused cutting for workshops and fabrication units.
Performance Specifications
| Models | MSD-1 CS |
|---|---|
| Capacity Round | 200 mm |
| Capacity Square | 175 mm |
| Gearbox | Standard |
| Drive Motor 440v AC 3 P. | 1 HP 1440 RPM |
| Coolant Pump 440v AC 3 P. | 0.15 HP 440 Volts |
| Blade Dim In mm | 2540 x 27
x 0.9 |
| Blade Speed m.min | 20-35-55-75 |
| Approx Dim in mm LxWxH | 1425 x 600 x 1200 |
| Net Weight Aprx. | 290 KG |
Machine Info
MSD-1CS model is simple manual bandsaw machine (Compact machine use for small Industries L-1425mm X W-600mm X H-1200mm), which is used mainly in workshops (use up to 8hours per day). The saw band is driven by V-belt step pulley, induction 3 phase motor & 3 phase coolant pump and an oil-bath worm reduction gearbox.
Machine is equipped with the Single-sided swiveling arm with angle positioning to cut 90° material. A dual acting vice with center job clamping ensure a parallel cut use of the bandsaw. The material clamping is done very easily by using a vice, whose movable jaw is guided by 2 hard chrome shafts and precise lead screw. During cutting, the material can be effectively clamped by both vice, Material feeding is carried out manually by hydraulic cylinder set by the arm of the operator.
Features
Hard chrome shafts in vice jaw for firm job holding
Hard chrome shaft in swiveling arm for stable operations
Precision taper bearings for gearbox & sliding wheel assembly
Adjustable cutting pressure regulator (spring-tension based)
Compact, space-saving design suitable for small workshops
Accessories
Adjustable job roller stand (150mm capacity)
Fixed table-type job roller stand (200mm capacity)
1 meter long job roller stand
Bi-metal bandsaw blade
Single-phase conversion option
Photo Gallery
Performance Specifications
| Models | MSD-1 HS | MSD-6 HS 250 |
|---|---|---|
| Capacity Round | 205 mm | 250 mm |
| Capacity Square | 175 mm | 225 mm |
| Gearbox | Standard / PB2 | PB2 |
| Drive Motor 440v AC 3 P. | 1 HP 1440 RPM | 1.5 HP 1440 RPM |
| Coolant Pump 440v AC 3 P. | 0.15 HP 440 Volts | 0.15 HP 440 Volts |
| Blade Dim In mm | 3000 x 27
x 0.9 | 3300 x 27
|
| Blade Speed m.min | 20-35-55-75 | 20-35-55-75 |
| Approx Dim in mm LxWxH | 1630 x 750 x 870 | 2000 x 750 x 950 |
| Net Weight Aprx. | 330 KG | 390 KG |
Machine Info
MSD-1HS, MSD-1HS PB2 and MSD-6HS PB2 models are simple manual bandsaw machine, which is used mainly in workshops (use up to 12 hours per day). The saw band is driven by V-belt step pulley, induction 3 phase motor & 3 phase coolant pump and an oil-bath worm reduction gearbox.
Machine is equipped with the Single-sided swiveling arm with angle positioning to cut 90° material. A dual acting vice with center job clamping ensure a parallel cut use of the bandsaw. The material clamping is done very easily by using a vice, whose movable jaw is guided by 2 hard chrome shafts and precise lead screw. During cutting, the material can be effectively clamped by both vice, Material feeding is carried out manually by hydraulic cylinder set by the arm of the operator.
Accessories
Adjustable job roller stand (150mm capacity)
Job roller stand fixed table type
Job roller stand fixed table type 1 meter long
Bi-metal bandsaw blade
Chip removing wire brush
Single phase machine available
Features
Hard chrome shafts in vice jaw for firm job holding
Hard chrome shaft use in swivelling arm for better griping
Taper bearing use in gearbox assembly & sliding wheel assembly
Adjustable cutting pressure regulator (work with spring tension) to increase/decrease the weight of the saw arm
PB2 heavy duty gear box for High efficiency use in model no. msd-1hs pb2 & msd-6hs pb2
Photo Gallery
Performance Specifications
| Models | MSD-2 HS | MSD-3 HS | MSD-4 HS | MSD-5 HS | MSD-7 HS 500 |
|---|---|---|---|---|---|
| Capacity Round | 315 mm | 350 mm | 400 mm | 450 mm | 500 mm |
| Capacity Square | 275 mm | 325 mm | 375 mm | 425 mm | 475 mm |
| Gearbox | PB2 | PB2 | PB2 | PB2 | PB2 |
| Drive Motor 440v AC 3 P. | 2 HP 960 RPM | 2 HP 960 RPM | 2 HP 960 RPM | 2 HP 960 RPM | 2 HP 960 RPM |
| Coolant Pump 440v AC 3 P. | 0.15 HP 440 Volts | 0.15 HP 440 Volts | 0.15 HP 440 Volts | 0.15 HP 440 Volts | 0.15 HP 440 Volts |
| Blade Dim In mm | 3760 x 27
x 0.9 | 4100 x 27 x 0.9 | 4420 x 27 x 0.9 | 4600 x 27 x 0.9 | 4600 x 27
|
| Blade Speed m.min | 20-35-55-75 | 20-35-55-75 | 20-35-55-75 | 20-35-55-75 | 20-35-55-75 |
| Approx Dim in mm LxWxH | 2400 x 930 x 1050 | 2550 x 930 x 1050 | 2650 x 930 x 1215 | 2750 x 930 x 1225 | 3000 x 930 x 1400 |
| Net Weight Aprx. | 650 KG | 710 KG | 850 KG | 900 KG | 950 KG |
Machine Info
MSD-2HS PB2, 3HS PB2, 4HS PB2, 5HS PB2 and 7HS PB2 models are simple manual bandsaw machine, which is used mainly in workshops (use up to 12 hours per day). The saw band is driven by V-belt step pulley, induction 3 phase motor & 3 phase coolant pump and an oil-bath worm reduction gearbox.
Machine is equipped with the Single-sided swivelling arm with angle positioning to cut 90° material. A dual acting vice with center job clamping ensure a parallel cut use of the bandsaw. The material clamping is done very easily by using a vice, whose movable jaw is guided by 2 hard chrome shafts and precise lead screw. During cutting, the material can be effectively clamped by both vice, Material feeding is carried out manually by hydraulic cylinder set by the arm of the operator.
Accessories
Job roller stand fixed table type
Job roller stand fixed table type 1 meter long
Bi-metal bandsaw blade
Chip removing wire brush
Single phase machine available
Features
Hard chrome shafts use in vice jaw for material better holding
Hard chrome shaft use in swivelling arm for better griping
Taper bearing use in gearbox assembly & sliding wheel assembly
Adjustable cutting pressure heavy duty stud (work with spring tension) to increase/decrease the weight of the saw arm
PB2 heavy duty gear box for High efficiency
