Special Purpose Machine Series
Precision-focused cutting for workshops and fabrication units.
Performance Specifications
| Models | MSD-1HS SPM |
|---|---|
| Cutting Capacity (mm) Round | 250mm in 90° / 125mm in 90° to 45° |
| Cutting Capacity (mm) Square | 225 × 225 mm in 90/ 125mm x 125mm in 90° to 45° |
| Cutting Capacity (mm) Rectangle | 250 x 200 |
| Blade Size (mm) | 3300 x 27 x 0.9 |
| Blade Speed mtr/min | 20/35/55/75 |
| Gearbox | PB2 heavy duty |
| Saw Motor Capacity (hp) | 20-35-55-75 |
| 415v ac, 50hz, 1400 rpm | 1.5 |
| Coolant pump Capacity (hp) | 290 KG |
| 415v ac, 50hz, 2800 rpm | 0.15 |
| Approx. Weight (Kg) | 390 KG |
| Overall Dimension (mm) L x W x H | 2150 x 770 x 1100 |
Machine Info
MSD-6HS PB2 model is simple manual bandsaw machine, which is used mainly in workshops (use up to 12 hours per day). The saw band is driven by V-belt step pulley, induction 3 phase motor & 3 phase coolant pump and an oil-bath worm reduction gearbox.
Machine is equipped with the Single-sided swiveling arm with angle positioning to cut 90° to 45° material. A single acting vice with job clamping ensure accurate cut use of the bandsaw. The material clamping is done very easily by using a vice, whose movable jaw is guided by 2 hard chrome shafts and precise lead screw. During cutting, the material can be effectively clamped by stable vice and movable vice, Material feeding is carried out manually by hydraulic cylinder set by the arm of the operator.
Accessories
Job roller stand fixed table type
Job roller stand fixed table type 1 meter long
Bi-metal bandsaw blade
Chip removing wire brush
Single phase machine available
Features
Hard chrome shafts use in vice jaw for material better holding
Hard chrome shaft use in swivelling arm for better griping
Taper bearing use in gearbox assembly & sliding wheel assembly
Adjustable cutting pressure regulator (spring-tension based)
PB2 heavy duty gear box for High efficiency
